MOS管为压控元件,你只需加到它的压控元件所需电压就能使它导通,它的导通就像三极管在饱和状态一样,导通结的压降最小.这就是常说的精典是开关效果.去掉这个操控电压经就截止。
MOS管的英文全称叫MOSFET(Metal Oxide Semiconductor Field Effect Transistor)，即金属氧化物半导体型场效应管，归于场效应晶体管中的绝缘栅型。因此，MOS管有时被称为场效应管。在一般电子电路中，MOS管通常被用于扩大电路或开关电路。
我公司代理的MOSFET涵盖了低压MOSFET的大部分封装，电压，电流，主推型号可以参考如下表格：
产品详情
|
Product Name |
Polarity |
with ESD |
Package |
Vds(V) |
ID(A) |
Vth(V) |
VGS(V) |
RDS (on) @10V,mΩ |
RDS (on) @10V,mΩ |
RDS (on) @4.5V,mΩ |
RDS (on) @4.5V,mΩ |
|
typ |
typ |
max |
typ |
max |
|||||||
|
JMTK320P06A |
P |
NO |
TO-252-4R |
-60 |
-30 |
-1.7 |
±20 |
23 |
30 |
27 |
38 |
|
JMTL84A |
P |
NO |
SOT-23 |
-50 |
-0.13 |
-1.5 |
±20 |
2200 |
3600 |
2600 |
5400 |
|
JMTL84K |
P |
YES |
SOT-23 |
-50 |
-0.13 |
-1.5 |
±20 |
2200 |
3600 |
2600 |
5400 |
|
JMTK130P04A |
P |
NO |
TO-252-4R |
-40 |
-40 |
-1.7 |
±20 |
10 |
13 |
15 |
22 |
|
JMTP130P04A |
P |
NO |
SOP-8 |
-40 |
-12 |
-1.7 |
±20 |
11 |
14.3 |
15.5 |
22 |
|
JMTK350P04A |
P |
NO |
TO-252-4R |
-40 |
-15 |
-1.6 |
±20 |
27 |
35 |
40 |
56 |
|
JMTK440P04A |
P |
NO |
TO-252-4R |
-40 |
-6 |
-1.5 |
±20 |
34 |
44 |
44 |
60 |
|
JMTP440P04A |
P |
NO |
SOP-8 |
-40 |
-6 |
-1.5 |
±20 |
36 |
47 |
47 |
66 |
|
JMTP850P04A |
P |
NO |
SOP-8 |
-40 |
-5 |
-1.6 |
±20 |
65 |
85 |
80 |
112 |
|
JMTL850P04A |
P |
NO |
SOT-23 |
-40 |
-5 |
-1.6 |
±20 |
70 |
90 |
90 |
125 |
|
JMTG050P03A |
P |
NO |
PDFN5X6-8L |
-30 |
-80 |
-1.5 |
±20 |
3.3 |
4.3 |
5.1 |
7.2 |
|
JMTK050P03A |
P |
NO |
TO-252-4R |
-30 |
-100 |
-1.5 |
±20 |
4 |
5.3 |
5.8 |
8.2 |
|
JMTK060P03A |
P |
NO |
TO-252-4R |
-30 |
-90 |
-1.6 |
±20 |
4.9 |
6.4 |
7.5 |
10.5 |
|
JMTG060P03A |
P |
NO |
PDFN5X6-8L |
-30 |
-75 |
-1.6 |
±20 |
4.3 |
5.6 |
7 |
9.8 |
|
JMTQ080P03A |
P |
NO |
PDFN3.3X3.3 |
-30 |
-45 |
-1.5 |
±20 |
5.8 |
7.5 |
9 |
12.6 |
|
JMTK080P03A |
P |
NO |
TO-252-4R |
-30 |
-60 |
-1.5 |
±20 |
5.8 |
7.5 |
9 |
12.6 |
|
JMTI080P03A |
P |
NO |
TO-251-4R |
-30 |
-60 |
-1.5 |
±20 |
5.8 |
7.5 |
9 |
12.6 |
|
JMTG080P03A |
P |
NO |
PDFN5X6-8L |
-30 |
-50 |
-1.5 |
±20 |
6 |
7.8 |
9 |
12.6 |
|
JMTP080P03A |
P |
NO |
SOP-8 |
-30 |
-15 |
-1.5 |
±20 |
7 |
9 |
10 |
14 |
|
JMTQ100P03A |
P |
NO |
PDFN3.3X3.3 |
-30 |
-40 |
-1.6 |
±20 |
7.5 |
10 |
11.6 |
16 |
|
JMTK100P03A |
P |
NO |
TO-252-4R |
-30 |
-55 |
-1.6 |
±20 |
7.5 |
10 |
11.6 |
16 |
|
JMTG100P03A |
P |
NO |
PDFN5X6-8L |
-30 |
-45 |
-1.6 |
±20 |
7.6 |
10 |
12 |
16.8 |
|
JMTK50P03A |
P |
NO |
TO-252-4R |
-30 |
-50 |
-1.5 |
±20 |
8.6 |
11 |
13 |
18 |
|
JMTQ4407A |
P |
NO |
PDFN3.3X3.3 |
-30 |
-35 |
-1.5 |
±20 |
8.6 |
11 |
13 |
18 |
|
JMTP4407A |
P |
NO |
SOP-8 |
-30 |
-12 |
-1.5 |
±20 |
9.3 |
14 |
14 |
20 |
|
JMTK160P03A |
P |
NO |
TO-252-4R |
-30 |
-45 |
-1.6 |
±20 |
10 |
14 |
16 |
22.5 |
|
JMTP160P03D |
Dual-P |
NO |
SOP-8 |
-30 |
-11 |
-1.6 |
±20 |
12.7 |
16.5 |
19 |
26.5 |
|
JMTP4407B |
P |
NO |
SOP-8 |
-30 |
-11 |
-1.6 |
±20 |
12.7 |
16.5 |
19 |
26.5 |
|
JMTP4435A |
P |
NO |
SOP-8 |
-30 |
-10 |
-1.5 |
±20 |
16 |
23 |
25 |
34 |
|
JMTP9435B |
P |
NO |
SOP-8 |
-30 |
-5.7 |
-1.5 |
±20 |
26.5 |
35 |
40 |
56 |
|
JMTP340P03A |
P |
NO |
SOP-8 |
-30 |
-7 |
-1.5 |
±20 |
27 |
35 |
38 |
54 |
|
JMTL3407A |
P |
NO |
SOT-23 |
-30 |
-4.1 |
-1.5 |
±20 |
42 |
55 |
62 |
85 |
|
JMTP4953A |
Dual-P |
NO |
SOP-8 |
-30 |
-5.1 |
-1.6 |
±20 |
43 |
55 |
66 |
90 |
|
JMTP9435A |
P |
NO |
SOP-8 |
-30 |
-5.1 |
-1.6 |
±20 |
43 |
55 |
66 |
90 |
|
JMTJ3407A |
P |
NO |
SOT-23-3L |
-30 |
-4.1 |
-1.6 |
±20 |
44 |
60 |
70 |
85 |
|
JMTL3401A |
P |
NO |
SOT-23 |
-30 |
-4.2 |
-0.9 |
±12 |
45 |
55 |
53 |
68 |
|
JMTJ3401A |
P |
NO |
SOT-23-3L |
-30 |
-4.2 |
-0.9 |
±12 |
48 |
60 |
57 |
78 |
|
JMTQ55P02A |
P |
NO |
PDFN3.3X3.3 |
-20 |
-55 |
-0.65 |
±8 |
- |
- |
6.6 |
8.5 |
|
JMTK50P02A |
P |
NO |
TO-252-4R |
-20 |
-60 |
-0.65 |
±8 |
- |
- |
6.6 |
8.5 |
|
JMTV210P02A |
P |
NO |
DFN2X2-6L |
-20 |
-12 |
-0.7 |
±12 |
- |
- |
17 |
22 |
|
JMTJ210P02A |
P |
NO |
SOT-23-3L |
-20 |
-7 |
-0.7 |
±12 |
- |
- |
18.7 |
24.5 |
|
JMTL2305A |
P |
NO |
SOT-23 |
-20 |
-4.1 |
-0.7 |
±12 |
- |
- |
32 |
42 |
|
JMTL3415K |
P |
YES |
SOT-23 |
-20 |
-4 |
-0.7 |
±8 |
- |
- |
38 |
48 |
|
JMTL3415KAEC |
P |
YES |
SOT-23 |
-20 |
-4 |
-0.7 |
±8 |
- |
- |
38 |
48 |
|
JMTL2301A |
P |
NO |
SOT-23 |
-20 |
-3 |
-0.7 |
±12 |
- |
- |
49 |
64 |
|
JMTL2301C |
P |
NO |
SOT-23 |
-20 |
-3 |
-0.7 |
±12 |
- |
- |
55 |
70 |
|
JMTL2301B |
P |
NO |
SOT-23 |
-20 |
-2.5 |
-0.7 |
±12 |
- |
- |
90 |
120 |
|
JMTD2004KNC |
P |
YES |
DFN1006-3L |
-20 |
-0.66 |
-0.65 |
±10 |
- |
- |
360 |
520 |
|
JMTL2004KT2 |
P |
YES |
SOT-23 |
-20 |
-0.66 |
-0.65 |
±10 |
- |
- |
360 |
520 |
|
JMTL2004KT3 |
P |
YES |
SOT-323 |
-20 |
-0.66 |
-0.65 |
±10 |
- |
- |
360 |
520 |
|
JMTL2004KT5 |
P |
YES |
SOT-523 |
-20 |
-0.66 |
-0.65 |
±10 |
- |
- |
360 |
520 |
|
JMTL2004KT7 |
P |
YES |
SOT-723 |
-20 |
-0.66 |
-0.65 |
±10 |
- |
- |
360 |
520 |
|
JMTL2004KDTW |
Dual-P |
YES |
SOT-363 |
-20 |
-0.66 |
-0.65 |
±10 |
- |
- |
360 |
520 |
|
JMTJ1216A |
P |
NO |
SOT-23-3L |
-12 |
-8 |
-0.7 |
±12 |
- |
- |
14.7 |
18 |
|
JMTV1216B |
P |
NO |
DFN2X2-6L |
-12 |
-16 |
-0.7 |
±12 |
- |
- |
11 |
15 |
|
JMTL2305B |
P |
NO |
SOT-23 |
-12 |
-4.1 |
-0.65 |
±12 |
- |
- |
26 |
36 |
